Wire and Cable Strippers

Automatic Wire Strippers & Cable Stripping Machines

Whether you’re working with coaxial, extruded, or magnet/enamel wire or cable, Eraser offers a wide range of stripper machine options. Remove the insulation from virtually all magnet and enamel wires of all sizes and insulation types, including Teflon. To check which of our wire strippers (by machine model number) will suite particular wire sizes, view Eraser’s Guide to Wire Stripping or contact one of our sales engineers. Designed to accommodate a wide range of wire stripping applications from automatic, air-operated, bench and portable machines, our complete line of strippers feature more than 40 products. Scroll down to view all our automatic wire stripper machines. And if you can’t find it here, we can custom build one for you!

Chemical Wire Strippers

Eraser Dip Strip Chemical Pots can remove the insulation from virtually all magnet and enamel wires of all sizes and insulation types, including litz wire without damage to the wire. Remove oxidation and residue with the dip clean 2. Dip Strip does not corrode conductors as will acid strippers. View Chemical Wire Strippers

Thermal Wire Strippers

Available in a lightweight hand held model or a bench model, thermal wire strippers are perfect for stripping solid and stranded wires up to 1/2″ OD. The HTS Series is especially effective on insulation such as P.T.F.E. and Teflon. The temperature at the stripping elements is variable up to 1400°F The bench model can be used for window stripping. View Thermal Wire Strippers

Fiberglass & Wire Wheel Strippers

Fiberglass wheels will strip many film type insulations. The conical wheels rotate at high speed to generate frictional heat which softens the insulation on the wire. The “nap” of the brush wipes this insulation away. Many of the machines work for square, rectangular, or flat magnet or enamel wire insulations including glass, varnish, epoxy and polythermaleze. View Wheel Strippers

Blade Strippers

Eraser blade strippers are great for round magnet and enamel wires with any type of film insulation, from solid and stranded wires and round cable and coax. Rotary strippers are the perfect machine if you need to cleanly remove insulation with no damage to the wire conductor. View Blade Strippers

DCF2/3 Wire Stripper for Magnet and Enamel Wire

DCF2/3 Wire Stripper for Magnet and Enamel Wire Part Number: AR4301

The DCF 2/3 stripper will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DCF4 Wire Stripper for Magnet and Enamel Wire

DCF4 Wire Stripper for Magnet and Enamel Wire Part Number: AR4401

The DCF 4 stripper will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DCF1 Wire Stripper for Magnet and Enamel Wire

DCF1 Wire Stripper for Magnet and Enamel Wire Part Number: AR4501

The DCF 1 stripper will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DCFR Wire Stripper for Magnet and Enamel Wire

DCFR Wire Stripper for Magnet and Enamel Wire Part Number: AR4801

The DCFR uses a rotating carbide rasp head to strip square, rectangular, or flat magnet or enamel wire insulations including glass, varnish, epoxy and polythermaleze. The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables it to be used as bench mounted machines.

C200 Wire Stripper

C200 Wire Stripper Part Number: AR4901

Designed for production, Eraser’s Model C200 Twin Blade Rotary Wire Stripper and Twister can process insulations such as Teflon, P.T.F.E., PVC, nylon, rubber, KEL-F and more from solid and stranded wires. The stripping head incorporates a pair of accurately adjustable tungsten carbide stripping blades. The blades are easily adjusted and remain on center. By reversing the belt, the unit may be operated with either clockwise or counterclockwise rotation. The slug may be left on the wire and removed later when terminated. Wire guides are not included and must be purchased separately.

LSAR20 Cable Stripper

LSAR20 Cable Stripper Part Number: AR6700

The LS series wire and cable strippers are precision wire and cable strippers. Blades are available to cover most applications and all are manufactured to exacting standards to provide a clean strip. Custom stripping blades can be manufactured for specific applications. Blades are quickly changed or adjusted. An adjustable strip length stop ensures consistent strip lengths. The LSAR20 is an air-operated versions of the LS series wire and cable strippers. The LSAR20 incorporates rubber covered clamps to eliminate markings. Select stripping blades as required.

LSA20 Cable Stripper

LSA20 Cable Stripper Part Number: AR6800

The LS series wire and cable strippers are precision wire and cable strippers. Blades are available to cover most applications and all are manufactured to exacting standards to provide a clean strip. Custom stripping blades can be manufactured for specific applications. Blades are quickly changed or adjusted. An adjustable strip length stop ensures consistent strip lengths. The LSA20 is an air-operated versions of the LS series wire and cable strippers. Model LSA20 incorporates standard serrated cable clamps. Select stripping blades as required.

C300 Triple Head Wire Stripper

C300 Triple Head Wire Stripper Part Number: AR9501

Designed for production, the Model C300 Twin Blade Rotary Wire Stripper and Twister will strip insulations from solid and stranded wires. The unit is capable of processing Teflon, P.T.F.E., PVC, nylon, rubber, KEL-F, miniature coax, coaxial cables,shielded wires and cables. The slug may be left on the wire and removed later when terminated. The stripping head incorporates a pair of accurately adjustable tungsten carbide stripping blades. The blades are easily adjusted and remain on center.

HBS1 Die Blade Wire Stripper

HBS1 Die Blade Wire Stripper Part Number: DE0007

This precision wire stripper is for wires insulated with problematic material. It is extraordinarily well suited for removing insulation from PMMA waveguides with PH sheath. The pliers are made of fiberglass reinforced polyamide with exchangeable blade.The HBS1 is suitable for wires with insulation of PVC, rubber, THHN, silicone, TPE, and THWN. It is applicable for use in the telecommunications, electrical and motor industries.

JCS Cable Stripper

JCS Cable Stripper Part Number: DE0035

A cable stripper with a unique adjustable depth swivel blade which cuts insulation on large cables both longitudinally and circumferentially, enabling insulation to be peeled off easily even for cables where insulation is molded tightly on conductors.

1256 Coaxial Cable Stripper

1256 Coaxial Cable Stripper Part Number: RC1071

The Model 1256 Stripper is a bench model stripper that can be used to strip coaxial cables, including semi-rigid, heliax, plenum and RGU. Powered by an AC motor and foot switch activated, the Model 1256 is easy and safe to use.

824 Portable Coaxial Cable Stripper

824 Portable Coaxial Cable Stripper Part Number: RC2000

Note: Unit comes with carrying case, charger and adapter cord. Designed for portability and weighing only two pounds (910 grams), the Model 824 Portable Coaxial Cable Stripper is battery operated and can be used to strip coaxial cables, including RGU, semi-rigid, plenum, heliax and more. The 824 can also process semi-rigid cable up to.141 inches OD (3.5mmø) easily. The standard battery pack provides approximately two hundred strips per charge. Note: Unit comes with carrying case, charger and adapter cord.

CS800 Wire Cut & Strip 120V

CS800 Wire Cut & Strip 120V Part Number: AR7201

Eraser’s Model CS800 Wire Cut & Strip is a fully programmable, fully electric bench top wire cutter and stripper. The unit can process wire from 10AWG – 30AWG and can quickly and precisely cut and partial strip 6,150 pieces per hour at 2.5” lengths (6.35 cmø), and 5,700 pieces per hour at 4’’ lengths (10.2 cmø). With programmable batching and ten variable feed rates, the CS800 is the perfect production tool for complete automation.

1256 Coaxial Cable Stripper (Drilled Through)

1256 Coaxial Cable Stripper (Drilled Through) Part Number: RC1068

Eraser’s Model 1256 Stripper is a bench model stripper that can be used to strip coaxial cables, including semi-rigid, heliax, plenum and RGU. Powered by an AC motor with a drilled out armature and foot switch activated, Model 1256 is easy and safe to use.

L1 Bench Wire Stripper

L1 Bench Wire Stripper Part Number: AR2041

Eraser’s Model L1 Bench Wire Stripper removes film insulations including enamel, Formvar, ML, armored poly-thermaleze, epoxy and more from round wires 29AWG to 13AWG. A high-speed rotating insert strips insulation from the surface of the wire.Close-up stripping is possible flush to a coil body or bobbin. Model L1 can also be used for other applications such as deflashing wires, cleaning legs of electronic components and cleaning pins on transformers and coils. The unit may also be used to clean round pins on transformers, wire wrap sockets, DIP sockets and relay sockets. The L1 can also remove oxidation, flashing, epoxy, and even contaminated solder.

DCF2/3 Drilled Wire Stripper for Magnet and Enamel Wire

DCF2/3 Drilled Wire Stripper for Magnet and Enamel Wire Part Number: AR4300

The DCF 2/3 stripper with drilled armature will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish. The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DCF1 Drilled Wire Stripper for Magnet and Enamel Wire

DCF1 Drilled Wire Stripper for Magnet and Enamel Wire Part Number: AR4500

The DCF 1 stripper will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DCF4 Drilled Wire Stripper for Magnet and Enamel Wire

DCF4 Drilled Wire Stripper for Magnet and Enamel Wire Part Number: AR4400

The DCF4 drilled stripper with armature will strip round magnet and enamel wires with any type of film insulation, including Formvar, nylon, polythermaleze and varnish The variable speed power unit controls the speed. Insulation is cleanly removed but the wire conductor is not damaged. This tool is ideal for the production and repair stripping of armatures, coils, chokes, transformers, relays, solenoids, etc. The optional Bench Kit enables all models to be used as bench mounted machines.

DSP3 Stripping Pot High Output 230V

DSP3 Stripping Pot High Output 230V Part Number: AR1232

The DSP stripping pots are designed specifically for use with Dip Strip. The DSP3 has an advanced feedback temperature controller and has a 600 watt heating element to increase the throughput 10 times. Dip Strip is used to chemically remove the insulation from virtually all magnet and enamel wires of all sizes and insulation types, without damage to the wire. When heated in the specially designed stripping pot, the Dip Strip melts and wires are immersed in the dip Strip to strip the insulation.The stripped wires are then rinsed in water and Dip Clean Metal Cleaner to remove oxides and residue. Dip Strip does not corrode conductors as will acid strippers.  Note: Contact Eraser’s Customer Service Department for shipping information.

HTS1C Thermal Wire Stripper

HTS1C Thermal Wire Stripper Part Number: AR0131

Lightweight hand held thermal wire strippers for stripping solid and stranded wires. The HTS Series is especially effective on insulation such as P.T.F.E. and Teflon. The temperature at the stripping elements is variable up to 1100°F (594°C). The HTS1C has a cradle switch. When the tool is placed in the cradle, heat to the elements is disconnected. The hand piece is only 7-1/8″ (181mm) long. A fiberglass brush is provided with each unit to clean the elements periodically.
