Replacement Parts

553 General Purpose FybRglass® Cone Wheels (Pair)

conewheels_web.jpg Part Number: AE0280
The 553 General Purpose Cone FybRglass® Wheels come in a pair and they are used for 30-36 AWG wire. All of our FybRglass® Stripping Wheels are manufactured in house to ensure the highest standards of quality and delivery. We make stripping wheels to fit all competitive machines as well as for all Eraser Models. We can also manufacture custom size wheels. There are many factors that determine the proper grade of FybRglass® wheel for a specific wire stripping application. These include wire size, type of insulation, strip length and number of wires stripped at one time. For this reason, we suggest you give us a call, to determine the proper grade for your application.

640 Fine FybRglass® Cone Wheels (Pair)

conewheels_web.jpg Part Number: AE0281
The 640 Fine Cone FybRglass® Wheels come in a pair and they are used for 35-48 AWG wire. All of our FybRglass® Stripping Wheels are manufactured in house to ensure the highest standards of quality and delivery. We make stripping wheels to fit all competitive machines as well as for all Eraser Models. We can also manufacture custom size wheels. There are many factors that determine the proper grade of FybRglass® wheel for a specific wire stripping application. These include wire size, type of insulation, strip length and number of wires stripped at one time. For this reason, we suggest you give us a call, to determine the proper grade for your application.

141 Extra Coarse FybRglass® Wheels (Pair)

AE0111_T.jpg Part Number: AE0353
The 141 Extra Coarse FybRglass® Wheels come in a pair and they are used for 24-26 AWG wire. All of our FybRglass® Stripping Wheels are manufactured in house to ensure the highest standards of quality and delivery. We make stripping wheels to fit all competitive machines as well as for all Eraser Models. We can also manufacture custom size wheels. There are many factors that determine the proper grade of FybRglass® wheel for a specific wire stripping application. These include wire size, type of insulation, strip length and number of wires stripped at one time. For this reason, we suggest you give us a call, to determine the proper grade for your application.

DE700 Compensating Dereeler

134.jpg Part Number: AR0170
The DE700 compensating dereeler prevents material over-runs when used with wire cutters or cut and strip machines. The dereeler provides fine adjustment control on the reel payout tension by means of a clutch.

Wheel Dresser

189.jpg Part Number: AR2701
Wheel dresser and handle for twin wheel strippers with wheels over 1″ (25mm) wide. For use with D1, DV1 and D9.

Wheel Dresser Refill

191.jpg Part Number: AR2702
Packet of 10 wheel dresser refills for use with wheel dresser for twin wheel strippers with wheels over 1″ (25mm) wide.

Wheel Dresser

637.jpg Part Number: AR2901
Wheel dresser for twin wheel strippers with wheels under 1″ (25mm) wide. For use with R1S, RT2, RT2S, ST1.

Wheel Dresser Refills

194.jpg Part Number: AR3020
Packet of 10 wheel dresser refills for use with wheel dresser for twin wheel strippers with wheels under 1″ (25mm) wide. For use with AR2901

M700C Modular Series Controller

M700C-Left.jpg Part Number: AR3300

The M700C (Control) Module is auto sensing and operates over the input power range of 100 – 240 VAC at 50/60Hz. While the feeder module (M700F) is optional, you will need to purchase one or more cutter modules (M700TW, M700ST, M700LT).

Use the M700C with the following Modules;

The M700F Feeder Module feeds material to precise lengths for cutting with other modules or can be used alone to feed compatible systems.

The M700TW Tube and Wire Cutter Module uses a pneumatic guillotine style cutter head to cut copper wire gauges up to 10 AWG stranded or 12 AWG solid and cut tubing up to 3/8” (9.5mm) OD.

The M700ST Small Tube Cutter Module utilizes Eraser’s rotary style cutter head that can cut many grades of tubing up to 1/2” (12.7mm) OD.

The M700LT Large Tube Cutter Module is a larger version of the rotary style cutter head that can cut tubing from 1/2” to 1-1/8” (12.7mm to 28.6mm) OD.

The M700HW Hard Wire Cutter Module utilizes a pneumatic-powered, dual-blade, semi-rotary style cutter which can cut various sizes of hard alloy wire.

The M700 Series is CE marked and RoHS compliant.

M700F Modular Series Feeder Unit

M700F.jpg Part Number: AR3400

The M700F (Feeder) Module feeds material to precise lengths for cutting with other modules or can be used alone to feed compatible systems.

The M700F Module features ten variable feed rates that allow the operator the flexibility to choose the correct rate for a given material to optimize production rate, repeatability and accuracy of the cut length. The M700F utilizes an adjustable, self-centering, dual stepper-driven belt feed.

The M700F is designed to work with the other M700 Series Modules.

The M700TW Tube and Wire Cutter Module uses a pneumatic guillotine style cutter head to cut copper wire gauges up to 10 AWG stranded or 12 AWG solid and cut tubing up to 3/8” (9.5mm) OD.

The M700ST Small Tube Cutter Module utilizes Eraser’s rotary style cutter head that can cut many grades of tubing up to 1/2” (12.7mm) OD.

The M700LT Large Tube Cutter Module is a larger version of the rotary style cutter head that can cut tubing from 1/2” to 1-1/8” (12.7mm to 28.6mm) OD.

The M700HW Hard Wire Cutter Module utilizes a pneumatic-powered, dual-blade, semi-rotary style cutter which can cut various sizes of hard alloy wire.

M700TW Modular Series Tube and Wire Cutter Unit

M700TW.jpg Part Number: AR3500

The M700TW (Tube and Wire) Cutter Module uses a guillotine style cutter head to cut copper wire gauges up to 10 AWG stranded or 12 AWG solid and cut tubing up to 3/8” (9.5mm) OD.

The M700TW Module easily and accurately cuts wire, tubing and sleeving to the programmed length and number of pieces when used with the optional M700F Feeder module. Ten variable feed rates allow the operator the flexibility to choose the correct rate for a given material to optimize production rate, repeatability and accuracy of the cut length. The M700TW utilizes a guillotine style cutter head. This unit can also be used in a manual cutting configuration.

M700ST Modular Series Small Tube Cutter Unit

M700ST.jpg Part Number: AR3600

The M700ST (Small Tube) Cutter Module utilizes Eraser’s rotary style cutter head that can cut many grades of tubing up to 1/2” (12.7mm) OD.

The M700ST Module is perfect for processing flexible tubing to tight specifications such as those required for medical applications. The M700ST is capable of processing materials such as flexible polyurethane, flexible PVC, nylon reinforced hose and rubber hose to the programmed length and number of pieces when used with the M700F Feeder module. This unit can also be used in a manual cutting configuration.

M700LT Modular Series Large Tube Cutter Unit

M700LT.jpg Part Number: AR3700

The M700LT (Large Tube) Cutter Module is a larger version of the rotary style cutter head that can cut tubing from 1/2” to 1-1/8” (12.7mm to 28.6mm) OD.

The M700LT Module is perfect for processing flexible tubing to tight specifications such as those required for medical applications. The M700LT is capable of processing materials such as flexible polyurethane, flexible PVC, nylon reinforced hose and rubber hose to the programmed length and number of pieces when used with the M700F Feeder module. This unit can also be used in a manual cutting configuration.

M700HW Modular Series Hard Wire Cutter Unit

M700HW.jpg Part Number: AR3800

The M700 Hard Wire Module (M700HW) utilizes a pneumatic-powered, dual-blade, semi-rotary style cutter which can cut various sizes of hard alloy wire, including Nitinol. The M700HW can be connected directly to the Control Module (M700C) or to a Control/Feeder setup (M700C + M700F) for automated material processing/cutting.

Some of the materials that the M700HW can be utilized for are Nitinol wire or Niti wire, fine carbon steel wire, Titanium wire, and Stainless Steel wire or cable. It can also be used for Piano wire, Surgical drive wire, Fine hard wire, and Stainless Steel micro wire or cable. The M700HW makes easy work of cutting hard material.

DE400 Bench Mounted Dereeler

199.jpg Part Number: AR3801
A bench mounted dereeler or reeler. Unit adjusts for reel hub diameter for various sizes up to 50lb.

Dip Strip

301.jpg Part Number: BR1301
Two pound (908g) bag of Dip Strip. Dip Strip is used to chemically remove the insulation from virtually all magnet and enamel wires of all sizes and insulation types, without damage to the wire. When heated in the specially designed stripping pot, Dip Strip melts and wires are immersed in the molten Dip Strip to strip the insulation. Note: Contact Eraser’s Customer Service Department for shipping information.
